How To Join Double Pitch Roof In Revit

Click modify tab geometry panel join unjoin roof.

How to join double pitch roof in revit. We want to join this face to the roof. Using shape editing tools. Revit roof slope can seem complicated at first glance but by learning a few critical features you can create any roof shape you desire. Then follow these 2 steps.

Then select the face of the roof you want to join in to and then. 9 join roofs add opening to create dormer. To create a dormer model required walls and additional roof. Groin vaults for your single groin needs 3 create a flat roof no edges defining slope then use the roof shape editing tools add split line set heights see attached revit file.

Then draw the arrow to define the slope direction. Use join unjoin roof tool. This tool is located in the modify tab. Http pbl stanford edu how to attach walls to roof objects in revit.

Select an edge of the roof that you want to join and then select the wall or roof to which you want to join the roof. If necessary use the viewcube to spin the design to facilitate selecting the wall or roof edges. 2 roof by extrusion needs to be cut and use multiple pieces as it turns corners this link explains a similar process fear and loathing in a cad vs. For creating complex roof it might be easier if you create separate roof then use join roof tool to join them later.

Whether you want a double gable roof with 6 pyramid shaped dormers or a simple gambrel roof the basics remain the same. You can use height or slope value specify the method and the constraint values from properties palette.
