How To Install Arb Awning Flush Mount

With the awning laid on its front slide the 20 millimetre bolts into the channel along the back of the awning.

How to install arb awning flush mount. Total cost is less than 20 00 made of aluminium and stainless. These channels line up exactly with the holes on the ladder rack brackets. Using caution drill the marked holes using a 5 16 drill bit. Instead of packing a clunky pop up awning with all those metal accordion braces consider running an arb awning mounted on the side of your roof rack.

First mount the awning brackets to your roof rack as far apart as possible. To mount the awning we decided to attach two bolts to each of the brackets. Arb awning installation overview on 5th gen 4runner roof rack similar to gobi bajarack and other mesh style roof racks when you need some shade the arb awning comes in pretty damn handy. I show you how i used the led light mounts from ebay to create some very nice awning mounts.

Lift the awning to the roof rack and ensure that the brackets are as far towards the ends of the awning as possible. Make sure awning is level before tightening completely.
